KY-036 Metal Touch Sensor Module

The KY-036 Metal Touch Sensor Module is an analog and digital sensor that uses a transistor to detect changes in electrical conductivity. When the metal pin is touched with a finger, the conductivity changes and the module outputs both a digital and an analog signal. The digital output functions as a touch activated switch, while the analog output measures touch intensity. The detection threshold can be adjusted using the onboard potentiometer. This module is compatible with Arduino, ESP32, ESP8266, Raspberry Pi, and similar microcontroller platforms.

Features:

• Metal touch sensor module (KY-036)
• Four pin interface
• Adjustable detection threshold via potentiometer
• Efficient for battery powered devices
• Provides both analog and digital outputs
• Includes red and green indicator LEDs
• Uses LM393 comparator chip
• Operating voltage: 5V
• Digital low level output signal
• Low power operation
• Adjustable touch sensitivity
• Compact and easy to use design
• Operating temperature: minus 20 degrees to 85 degrees

Pin Configuration:

• Pin 1 (Digital Signal): Outputs a digital signal when the metal tip is touched
• Pin 2 (VCC): Positive power supply input
• Pin 3 (GND): Ground connection
• Pin 4 (Analog Signal): Outputs the direct analog measurement value

Package Includes:

• 1 x KY-036 Metal Touch Sensor Module
